molex micro-fit 3.0 12-pin cables & pigtails, built to your length.
43025-1200 receptacle · 43020-1201 plug · genuine Molex parts · priced instantly · free 2-day shipping.
Price
the price, before you ask for it.
| build | qty 1, each | qty 10, each | qty 50, each | configure |
|---|---|---|---|---|
| cable, 12 in (305 mm) | $41.86 | $39.77 | $37.67 | configure |
| cable, 24 in (610 mm) | $53.38 | $50.71 | $48.04 | configure |
| pigtail, 12 in (305 mm) flying leads | $40.00order minimum | $31.48 | $29.83 | configure |
| pigtail, 12 in (305 mm) leads with ferrules | $41.30 | $39.24 | $37.17 | configure |
each · free UPS 2-day shipping · $40 order minimum (a smaller order is charged $40) · ships in 8 business days. these are example builds: change the length, pinout and colors in the configurator and it prices the result the same way.
Drawing
the 12 in (305 mm) cable, pin for pin.
pin 1 to pin 1 straight through, 20 AWG in the standard color order. the configurator draws the same diagram for your own configuration, and exports it as a PDF.
Parts
what it's built from.
| receptacle housing | 43025-1200 | also written 430251200 |
|---|---|---|
| plug housing | 43020-1201 | also written 430201201 |
| pin contact — standard (tin) | 43031-0001 | 20–24 AWG |
| socket contact — standard (tin) | 43030-0001 | 20–24 AWG |
| pin contact — gold-plated | 43031-0002 | 20–24 AWG |
| socket contact — gold-plated | 43030-0002 | 20–24 AWG |
| wire | UL1007 | 20, 22, 24 AWG |
part numbers link to Digi-Key, where we buy them — genuine Molex, new, traceable.
Pitch
3 mm
Wire
20–24 AWG
Length
5–48 in (127–1219 mm)
Lead time
8 business days
Questions
about the 12-pin molex micro-fit 3.0.
- can I order just one 12-pin cable?
- yes, there's no minimum quantity. one 12 in (305 mm) 12-pin cable is $41.86, and shipping is free (UPS 2-day). the order minimum is $40. prices drop at 10 and 50 units.
- which half holds the pins?
- the 43025-1200 receptacle holds socket contacts, and the 43020-1201 plug holds pin contacts. every contact is crimped with Molex's own specified tooling.
- what wire gauges and lengths?
- 20, 22, 24 AWG UL1007 hook-up wire, any length, 5–48 in (127–1219 mm). the prices above are at 20 AWG.
- how fast does it ship?
- it's built and shipped in 8 business days, then goes out UPS 2-day.
more in the FAQ, including returns (custom cables are non-returnable; defects replaced).
