DB15 D-sub pigtails & cables, built to your length.
DA15S064TLF receptacle · DA15P064TXLF plug · genuine Amphenol parts · priced instantly · free 2-day shipping.
Price
the price, before you ask for it.
| build | qty 1, each | qty 10, each | qty 50, each | configure |
|---|---|---|---|---|
| cable, 12 in (305 mm) | $57.80 | $54.91 | $52.02 | configure |
| cable, 24 in (610 mm) | $68.60 | $65.17 | $61.74 | configure |
| pigtail, 12 in (305 mm) flying leads | $42.34 | $40.22 | $38.11 | configure |
| pigtail, 12 in (305 mm) leads with ferrules | $54.34 | $51.62 | $48.91 | configure |
each · free UPS 2-day shipping · $40 order minimum (a smaller order is charged $40) · ships in 10 business days. these are example builds: change the length, pinout and colors in the configurator and it prices the result the same way.
Drawing
the 12 in (305 mm) cable, pin for pin.
pin 1 to pin 1 straight through, 22 AWG in the standard color order. the configurator draws the same diagram for your own configuration, and exports it as a PDF.
Parts
what it's built from.
| receptacle housing | DA15S064TLF | DA-15 |
|---|---|---|
| plug housing | DA15P064TXLF | DA-15 |
| hood — plastic hood | 17E17251 | your choice |
| hood — metal hood | 17E165715 | your choice |
| wire | UL1007 | 20, 22, 24 AWG |
part numbers link to Digi-Key, where we buy them — genuine Amphenol, new, traceable.
Pitch
2.77 mm
Wire
20–24 AWG
Length
5–48 in (127–1219 mm)
Lead time
10 business days
Questions
about the DB15 D-sub.
- can I order just one DB15 cable?
- yes, there's no minimum quantity. one 12 in (305 mm) DB15 cable is $57.80, and shipping is free (UPS 2-day). the order minimum is $40. prices drop at 10 and 50 units.
- are the contacts crimped or soldered?
- soldered. these shells come with solder-cup contacts built in, so each wire is soldered into its cup with lead-free solder — there's no separate contact to choose.
- which hoods can I choose?
- plastic hood (17E17251) or metal hood (17E165715). the hood is included in the price and fitted on every connector.
- what wire gauges and lengths?
- 20, 22, 24 AWG UL1007 hook-up wire, any length, 5–48 in (127–1219 mm). the prices above are at 22 AWG.
- how fast does it ship?
- it's built and shipped in 10 business days, then goes out UPS 2-day.
more in the FAQ, including returns (custom cables are non-returnable; defects replaced).
